Retaining wall restoration
Repair and stabilization of shoring and retaining walls. We address structural issues, drainage problems, and surface deterioration.
→ Wall stability
→ Erosion control
→ Extended lifespan
→ Safety compliance
Walls Repaired
Years Experience
Failures
Inspect wall condition
Install temporary support if needed
Apply shotcrete or fix anchors
Ensure proper drainage
Timeline depends on repair extent. Simple drainage improvements take 2-3 days. Shotcrete applications for spalling repairs take 3-5 days. Major structural stabilization with ground anchors or soil nails may take 2-4 weeks. We provide detailed schedules after initial structural assessment and geotechnical review.
Yes, properly executed shoring wall repairs are permanent. Shotcrete applications bond permanently to existing concrete. Ground anchors and soil nails provide permanent load transfer to stable soil. We provide 5-10 year warranties depending on repair extent and ongoing maintenance requirements.
Common failure causes include drainage failure (water pressure buildup), reinforcement corrosion weakening load capacity, inadequate anchor maintenance, soil movement from adjacent excavation, and aging concrete deterioration. We conduct geotechnical assessment including soil testing and drainage analysis to identify root causes before designing repairs.
Costs vary significantly. Simple drainage upgrades cost $3,000-8,000. Shotcrete repair of 50 sqm spalling costs $8,000-15,000. Major structural repairs with new anchors or soil nails range $30,000-100,000 depending on wall height and soil conditions. Geotechnical assessment required for accurate quoting.
Minor drainage repairs and shotcrete patching allow normal property use with temporary fencing for safety. Major anchor or soil nail installation typically requires restricted access to the work area but doesn't necessitate full property evacuation. We minimize disruption through careful work sequencing and scheduling.
Yes, we recommend geotechnical assessment for all shoring wall repairs exceeding simple maintenance. Assessment identifies underlying soil conditions, bearing capacity, drainage patterns, and appropriate repair methods. Certified geotechnical reports are required for major repairs and ensure long-term stability.
Our retaining wall on the Northern Beaches property was showing serious cracks and leaning outward. TRD's geotechnical assessment identified drainage failure as the root cause. Their shotcrete repair and drainage upgrade completely stabilized the wall. We have confidence it will last another 30+ years.
"After adjacent excavation damaged our carpark retaining wall, TRD provided emergency assessment and stabilization within 48 hours. They installed temporary support, then completed permanent soil nail reinforcement. Fast response, excellent engineering, and complete peace of mind.
"Contact us for a free consultation and site assessment.
